- 10.4" fanless system with resistive touch screen
- System memory up to 2 GB SDRAM
- Built-in 802.11b/g Wireless LAN
- Built-in Bluetooth module
- Built-in two 1.5 W speakers
- Built-in HSDPA module for mobile connection (Optional)
- One compact flash slot
- IP 64 compliant front panel
IEI IQ mount design allows the AFOLUX series to be easily integrated into a diverse variety of applications. The arm design can be used for industrial controls, the panel mount for kiosk devices, the wall mount for e-home terminals and the stand design for thin client applications.
| LCD Size | 10.4" |
| Max.Resolution | 800x600 |
| Brightness | 500cd/m² |
| LCD Color | 262K |
| Pixel Pitch(mm) |
0.213(H) x 0.231(V) mm |
| Contrast Ratio | 500:1 (Typ.) |
| View Angle H-V | 120(H)x100(V) |
| Backlight MTBF | 50000hrs |
| SBC/CPU |
AFLMB-ATOM-R10, N270 (Atom 1.6G) |
| Chipset |
Intel 945GSE / ICH7M |
| RAM |
Intel 945GSE / ICH7M 533MHz DDR2 SO-DIMM |
|
Watchdog timer |
Software programmable supports 1~255 sec. System reset |
| I/O Ports |
1 x RS-232 |
| Audio |
AMP 1.5W + 1.5W |
| Touchscreen |
Resistive Type 4-Wire (touch controller IC is on board) |
| Expansion Slot |
1 x Wireless LAN Module (Mini PCI Interface ), 1 x Bluetooth Module (USB Interface, Bluetooth V2.0) |
| HDD Drive Bay | N/A |
| SSD |
CF Type II slot |
| FDD Drive Bay | N/A |
| CD-ROM Drive Bay | N/A |
| Contruction front panel |
ABS + PC Plastic front frame, Gray color 7539U |
| Power adapter |
P/N: 63000-FSP0361AD101C-RS Power: 36W Input: 90VAC~264VAC @ 50/60Hz Output:12VDC |
| Power consumption |
12V/28W |
| Mounting |
Panel, Wall, Rack, Stand or Arm VESA 75mm x 75mm |
| Front Panel Protection | meets IP64 |
| Operation Temperature | -10°C~50°C with Industrial CF Card |
| Dimension(WxDxH) mm |
234 x 184 x 42 |
| EMC/Safety |
CE, FCC Class B,and CCC / UL, CB |
| Weight | 1.4kg |
Order Information
AFL-10A-ATOM-N270/WT-R/1GB-R10 10.4" 400cd/m2 SVGA fanless panel PC with Intel® AtomTM N270 1.6GHz,802.11b/g wireless module,bluetooth module, touch screen,1GB DDR2 533,RoHS
Mounting kits, WinCE5.0 or XPEmbedded image on CompactFlash card.
