Specially developed for installation in cars, boats and lorries
-
Measuring computer and control computer for vehicle testing
-
Communication computer with internal GSM, WLAN, LAN and GPS
-
Infotainment computer
| CPU |
Intel® Pentium® C140, 1GHz |
| 2nd Level Cache |
0kB, 512kB option |
| Chipset |
Intel® 855GME |
| Memory |
256MB (max. 1GB) |
| Hard drive |
0GB, 2.5" (max. 40GB), Opt. SSD |
| Optical drive |
Optional |
| Video Controller |
Intel® 855GME |
| Video Memory |
64MB |
| 3D Support |
DirectX 9 |
| Video Interface 1 |
QXGA |
| Video Interface 2 |
DVI |
| Video Interface 3 |
- |
| Resolution |
2048 x 1536 (@ 75Hz) |
| Keyboard and Mouse |
USB |
| Serial Interface COM1 |
RS232C |
| Serial Interface COM2 |
RS232C |
| Serial Interface COM3 |
Optional |
| Serial Interface COM4 |
Optional |
| Parallel Interface |
LPT |
| USB V2.0 |
4x back, 2x front |
| Firewire IEEE1394 |
1x front, 1x back option |
| TV Input / Frame grabber |
BT878A, SVideo, 3 channels |
| LAN port A (with LAN boot) |
10/100BASE-T (RJ45) |
| LAN-Port B |
- |
| LAN-Port C |
- |
| SCSI | - |
| Audio controller |
AC97-2.3 |
| Line Output |
Stereo |
| Line Input/mic. input |
Stereo |
| SPDif output |
yes |
| Option 1 |
WLAN MiniPCI |
| Option 2 |
Dual-CAN |
| Option 3 | GSM |
| Option 4 | GPS |
|
Digital input/output |
Option: 3x isol. in/ 3x relay out |
|
Remote power on/off |
yes |
|
Voltage input/power |
8V-30V DC / typ. 15W |
|
Plug-in power supply |
110/220V AC option |
|
Expansion |
MiniPCI, PC/104-Plus |
|
Power save function |
Suspend/Resume, SoftOff, Instant On |
|
Conformity |
CE, FCC |
|
Protection class |
IP52 |
|
Size (W x L x H in mm) |
159 x 190x 66 |
|
Weight |
3 kg |
|
Housing |
Aluminium |
|
Colour |
anthracite/black anodized |
|
Noise level |
<20dB(A) |
|
Operating temperature (with HD) |
-20°C to +50°C |
|
Extended operating temperature |
-40°C to +70°C (SSD, no CD/HD) |
|
Vibration/shock incl. HD/CD/DVD |
1/10G |
|
Vibration/shock incl. SSD |
16/150G |
|
MTBF |
60'000 hrs. |
|
For operating systems |
WIN2000, WIN XP, LINUX |
Ordering Information:
Item No. Description MPCX48 814300 with SM855-C140 (1GHz), without HD, 256MB-RAM, CompactFlash, 1x USB-Boot stick, 1GB Item No. Description Upgrade 814305 SM855-C373 (1.0GHz) to 512MB RAM 807362 to 1GB RAM Item 814314 HD 40GB–E28–24h 814315 DVD/CD 814317 SSD 16GB E48 14320 3ch relay out 814325 Front cover IP52 814330 WLAN – MPCX48 814335 GPS – MPCX48 814343 GSM, TriBand GPRS (MC55) 814341 GSM, GPRS/EDGE (MC75) 814342 Wakeup from GSM COM3/4 2x CAN Peak Preheat -40°C for HD/CD Power supply 220V USB-boot stick (DOS/Linux)
807361
No.
Description
Option
814375
814369
814345
814380
814350
