High Speed Link - Real-time Distributed I/O
|
||
|
||
|
HSL-DO32-M-N/HSL-DO32-M-P 32-CH Discrete Output Module
- Slave ID consumption: 2 consecutive from odd
- 32-CH digital output -N: NPN sinking type output -P: PNP sourcing type output
- Switch capacity: Single channel 500mA; all channels 60mA at 24VDC
- Photo couple isolation voltage: 2500Vrms
- Response time: ON/OFF: 180µs, OFF/ON :1.2µs
- LED indicator: Power, Link and Output status
- Power supply: +10V to +30 VDC
- Operating temperature: 0 to 60°C
